Pressure Differential

  • Digital Differential Pressure Switches 2 setpoint
Digital Differential Pressure Switches 2 setpoint

Digital Differential Pressure Switches 2 setpoint

  • CE certificate
  • ATEX explosion proof is available
  • Product description: GE-209D differential pressure controller is a digital differential pressure switch. It has two differential pressure setting values, and the action value of the differential pressure switch can be pre
  • INQUIRY

GE-209D differential pressure switch adopts diffusion silicon differential pressure sensor and stainless steel case, the two pressure interfaces can be connected on the measured pipeline or impulse line, suitable for measuring differential pressure of gas and liquid.


Character:

* Two independently adjustable set points with fixed dead band.
* Ingress protection: IP66
* Dead band: narrow, fixed.
* Process connections: M20x1.5 Male thread or others.
* Process fluid: water
* Range: 0-1.0 bar****35.00bar max
* Factory adjusted set points:
* Min. Set point = 380 mbar (decreasing)
* Max. Set point = 2 bar to 35bar (increasing)

Digital Differential Pressure Switches

Specification:

Pressure Range : 0...3.5MPa

Accuracy:  ≤0.5%F.S
Power Supply: 24VDC/220VAC
Overload Capacity: 150%F.S.
Response Time:  <30ms
Pressure Type:  Differential Pressure
Stability:  <0.1%/year
Display: 0.56" Nixie Tube
Display Range: -1999~9999
Medium Temperature:  -40~150℃(Heat radiator must be used if medium temperature over 80℃)
Operating Temperature:  -30~80℃
Relative Humidity: 0-90%
